Skip Hoist- Hooklift / Armroll

4x Image

TH-3800 X 750

BRAND : TOP HOIST
MODEL : TH-3800 X 750
(A)OUTSTRETCH OVERALL LENGTH (MM) : 3660
(B)CHASSIS WIDTH (MM) : 750
(C)REAR ROLLERS WIDTH (MM) : 1070
(D)MAX JIB HEIGHT (MM) : 1200
MAIN CYLINDER LENGTH (MM) : 1380
CYLINDER DIAMETER (MM) : 120
CYLINDER ROD DIAMETER (MM) : 60
MAX LIFTING CAPACITY (KG) : 6000
TOTAL WEIGHT (KG) : 1000
4x Image

TH-3800 X 850

BRAND : TOP HOIST
MODEL : TH-3800 X 850
(A)OUTSTRETCH OVERALL LENGTH (MM) : 3660
(B)CHASSIS WIDTH (MM) : 850
(C)REAR ROLLERS WIDTH (MM) : 1070
(D)MAX JIB HEIGHT (MM) : 1200
MAIN CYLINDER LENGTH (MM) : 1380
CYLINDER DIAMETER (MM) : 120
CYLINDER ROD DIAMETER (MM) : 60
MAX LIFTING CAPACITY (KG) : 6000
TOTAL WEIGHT (KG) : 1050
4x Image

TH-4200 X 750

BRAND : TOP HOIST
MODEL : TH-4200 X 750
(A)OUTSTRETCH OVERALL LENGTH (MM) : 4150
(B)CHASSIS WIDTH (MM) : 750
(C)REAR ROLLERS WIDTH (MM) : 1070
(D)MAX JIB HEIGHT (MM) : 1200
MAIN CYLINDER LENGTH (MM) : 1570
CYLINDER DIAMETER (MM) : 120
CYLINDER ROD DIAMETER (MM) : 60
MAX LIFTING CAPACITY (KG) : 7000
TOTAL WEIGHT (KG) : 1100
4x Image

TH-4200 X 850

BRAND : TOP HOIST
MODEL : TH-4200 X 850
(A)OUTSTRETCH OVERALL LENGTH (MM) : 4150
(B)CHASSIS WIDTH (MM) : 850
(C)REAR ROLLERS WIDTH (MM) : 1070
(D)MAX JIB HEIGHT (MM) : 1200
MAIN CYLINDER LENGTH (MM) : 1570
CYLINDER DIAMETER (MM) : 120
CYLINDER ROD DIAMETER (MM) : 60
MAX LIFTING CAPACITY (KG) : 7000
TOTAL WEIGHT (KG) : 1150
